Rotary Screen

    Rotary screen is composed of the rack and cylindrical screen, and it’s powered by electric motors.
Rotary Screen

Rotary screen is commonly used screening equipment, widely used in stone plant and concentrating plant for sieving of gravel and other granular materials, so it's also called gravel screen,  rotary screener or stone seperator.

Rotary screen is composed of the rack and cylindrical screen, and it's powered by electric motors. Rotary sieve is inclined, so after materials being fed into the drum, eligible items come out of mesh screen due to its rotating in tilt angle; while substandard materials will be left in the drum, and discharged from the rear end of the drum.

Rotary Screen

Parameters type

Model Yield(m³/h) Power
(kw)
Sieve hole(2mm) Sieve hole(30mm)
YTS1230 12 100 5.5
YTS1240 14 120 5.5
YTS1250 15 140 5.5
YTS1530 18 150 5.5
YTS1540 18 150 7.5
YTS1550 20 180 11
YTS1560 22 200 11
YTS2040 25 250 15
YTS2050 30 300 15
YTS2060 35 350 18.5
Please enter your questions, such as ball mill: the type of raw material, feed size, capacity, specifications and the final product size, we will answer your questions as quickly as possible according to your needs. Now purchasing our products will enjoy the lowest discount, please call our hotline: 0086-0371-63313738
